ID # 37661816
Case IH Heavy-Offset Disk Harrows 790
Call for Price
Overview
Specifications
literature
Documents
Heavy-Offset 790All-Purpose heavy offset disk harrow, with 10.5 - 12 inch blade spacing and 28 - 32 inch blades, comes as an all-urpose offset or plowing disk to perform a wide array of soil-conditioning tasks. |
Unmatched Ruggedness, Dependability and PerformanceCase IH Heavy-Offset 790 disk harrows are engineered to provide consistent performance over years of use. Featuring durability-enhancing design, adjustability to fit varying conditions and self-sharpening Earth Metal® blades. |
Model
Heavy-Offset
Category Name
Agriculture
Year
2025
Sale Type
New
Manufacturer
Case IH
Disk Bearings
Self-aligning, cartridge type ball bearings
Transport Widths
11 to 27-ft.
Transport Tires
12.5 x 15FI
Disk Blade Scraper
Spring type, adjustable
Disk Harrow Type
Offset
Gang Arbor Bolts In
1.5
Disk Blade Spacing
10.5 - 12 in (267 - 305 cm)
Disk Blade, Diameter
28 - 32 in (711 - 812 cm)
Disk Blade Diameter In
28
Disk Spool Diameter In
6
Disk Blade Spacing In
10.5
Transport Wheel Mounting
Two sets of side-by-side tires with axles on rockshaft wheel arms
Blade Edge Profile
Notched
Number Of Widths Available
3
Rear Gang Angle - Degrees
34 to 46 included angle
Folding
Folding
Front Gang Angle - Degrees
34 to 46 included angle
Gang Mounting To Frame
Fixed
Max Working Width Ft-in
27ft 2in
Optional Blade Edge Profile
Smooth
Max Total Weight Lb
15500
Literature
| Name | Link |
| EXCEL | Download |
Documents
CompareSpecs.xlsx Model
Heavy-Offset
Category Name
Agriculture
Year
2025
Sale Type
New
Manufacturer
Case IH
Quantity
1
Disk Bearings
Self-aligning, cartridge type ball bearings
Transport Widths
11 to 27-ft.
Transport Tires
12.5 x 15FI
