Case IH True-Tandem 335VT

Videos
Call for Price
Overview

True-Tandem 335VT

With this workhorse’s combination of Agronomic Design features and rugged components, producers can take on heavy residue, uneven ground and rocky conditions. Add the optional Soil Command tillage technology for in-cab adjustments to get the most out of your workday.

Achieve Optimal Field Conditions

Our vertical tillage lineup is built on proven Agronomic Design™ principles with industry-exclusive blades. The True-Tandem 335VT and 335 Barracuda vertical tillage tools cover more ground in less time, so your fields are ready to go when your planting window approaches. Ideal for conservation to conventional tillage farming practices for varying sized operations, the VT-Flex™ 435 vertical tillage tool offers simple variable gang angle adjustments — from effectively sizing residue and preserving soils to mixing the most stubborn crop residue.

All vertical tillage equipment is available with Case IH Soil Command tillage technology that delivers greater accuracy, consistency, and data insights to make your operation more efficient. All adjustments are made on-the-go from the comfort of your cab.

Specifications
Model
Vertical Tillage
Category Name
Agriculture
Year
2025
Sale Type
New
Manufacturer
Case IH
Blade Size
20 in (508 mm)
Blade Type
Earth Metal VT Wave Blade
Description
Double Edge Rolling Reel
Max Weight Lb
21588
Blade Mounting
Gangs
Blade Concavity
Slight concavity
Sizes Available
5
Blade Spacing In
7.5
Transport Widths
14 ft 6 in (4.42 m) - 18 ft 6 in (5.64 m)
Blade Diameter In
20
Blade Edge Profile
Wave pattern, can be sharpened
Primary Blade Type
Wave blade
Rolling Diameter In
14
Fore-aft Configuration
Blade-Blade-Rolling reel
Max Working Width Ft-in
34ft 1in
Max Transport Width Ft-in
18ft
Max Transport Height Ft-in
13ft 7in
Bars Or Blades On Circumference
Formed double edge on each bar
Rear Angle Of Gang Or Blades - °
18
Front Angle Of Gang Or Blades - °
18
Manufacturer's Description Of Blades
Earth Metal VT Wave Blade
